OAK-1 W PoE

$349.00 VAT incl.

NEW
In stock
19 PCS

Recently introduced model combining OAK-1 PoE body (and IP67 rating) with a new range of applications brought about by wide field of view camera.

  • Either 120° or 150° DFOV depending on variant chosen
  • Rugged IP67 rated enclosure
  • 4 TOPS of processing power
  • RJ45 for power delivery and communication
Read more
SKU: OAK-1-W-PoEN/A

RGB Camera: IMX378 WFOV

  • IMX378 WFOV
  • OV9782 WFOV
Out of stock
Description of the image



Works with RobotHub

  • Remote monitoring
  • Live streaming
  • Easy app deployment
  • Plug & Play setup
  • App store





  1. CE Certificate


OAK-1 W PoE is an 12MP AI camera that features on-device Neural Network inferencing and Computer Vision capabilities. It can capture high-resolution images, run custom AI models, and perform advanced computer vision tasks. It uses PoE for both power and GigE connectivity.

Wide FOV allows you to capture more area in one shot, which can be especially useful for:

  • Multi-camera setup, to reduce the number of cameras needed to cover the whole area
  • AMRs, to cover larger area and to get more features for localization and 3D mapping - see VIO/SLAM documentation for more information
  • Object tracking/counting, for example vehicle or people counting over a larger area

PoE connection allows cameras to communicate to other computers via networking protocols (TCP, UDP, HTTP, MQTT, etc.). As our PoE models feature device flash memory, you can also run your programs in standalone mode. OAK PoE cameras are housed in an rugged, IP-rated enclosure, which is required for industrial and outdoor use.

We suggest following Getting started with OAK PoE devices as the first steps after installation.



Central RGB Camera:

Available in two variants: IMX378 wide FOV or OV9782 Wide FOV sensor

Sensor

IMX378

OV9782

DFOV / HFOV / VFOV

120° / 95° / 70°

150° / 127° / 79.5°

Resolution

12MP (4056x3040)

1MP (1280x800)

Focus

FF: 60cm - ∞

FF: 19.6 cm - ∞

Max Framerate

60 FPS

60 FPS

IR Sensitive With IR filter With IR filter
Shutter Type Rolling Global

  • OAK-1 W PoE camera
  • Ethernet cable, 2m
  • Cable gland

PoE injectors are not included in the package.
